Tenda O1 User Manual

58
CPE2 to CPE5:
CPE
SSID
WLAN MAC address
CPE2
Tenda_2
C8:3A:35:01:8C:C9
CPE3
Tenda_3
C8:3A:35:35:BA:01
CPE4
Tenda_4
C8:3A:35:FD:8D:A1
CPE5
Tenda_5
C8:3A:35:09:93:51
Configuration procedures
When setting the Base Station to P2MP mode, ensure that the Base Station and all CPEs operate in the
same channel.
Step 1 Set CPE2 to Repeater mode and bridge to the CPE1.
1. Log in to the web UI of CPE2, choose Quick Setup, select Repeater mode, and click Next.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
