Tenda O1 User Manual

85
5.3.5 Routing table
It specifies the destination networks that the device can access.
To access the page, log in to the web UI of the device, and choose Status, then Routing Table in
Statistics part.
Parameters description
Name
Description
Destination Network
It specifies the IP address of the destination network.
Subnet Mask
It specifies the subnet mask of the destination network.
Next Hop
It specifies the IP address of entrance of the next hop route when the packets egress
from the interface of the device.
Interface
It specifies the interface that the packets egress.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
