Tenda TEG1016G User Manual

LED indicators of the TEG1024G Switch
Please refer to the list below for the LED indicator definition.
LED Indicator Status Description
POWER
Always ON Indicates the Switch is powerd on
OFF Indicates the Switch is powerd off
1000Mbps ON The Switch connects to the other
devices at 1000Mbps speed.
OFF Indicates there’s no connection or the
speed is at 10Mbps or 100Mbps
LINK/ACT
Flashing Indicates the switch is transmitting
data
Always ON Indicates no data is being
transmitting
2. Installation
2.1 Installation instructions
Before connecting to the network, please pay attention to the following
5

Tenda TEG1016G Specifications

General

MAC address table	8000 entries
Maximum data transfer rate	1 Gbit/s
Supported data transfer rates	10/100/1000 Mbps
10G support	No
Full duplex	Yes
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Size (imperial)	19 \
Dimensions (WxDxH)	208 x 440 x 44 mm
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet
Connectivity technology	Wired
Switch type	Unmanaged
Switch layer	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
SFP/SFP+ slots quantity	0
Gigabit Ethernet (copper) ports quantity	16
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Form factor	1U
Certification	CE, RoHS
Product color	Blue
LED indicators	Link, Power
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Output power	20 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	440 mm
Width	208 mm
Height	44 mm
