11N Wireless Broadband Router
72
¾ Destination LAN IP: The address of the remote
host with which you want to construct a static
route.
¾ Subnet Mask: The network portion of the
Destination LAN IP.
¾ Gateway: The gateway of the next hop, usually
the Router or host’s IP address.
Note
1. The gateway must keep the same segment with
the Router’s LAN IP address.
2. If the destination IP address is one host’s IP
address, the Subnet mask should be
255.255.255.255.
3. If the destination IP address is an IP address
range, the subnet mask should match the IP
address. For example, if the IP is 10.0.0.0, subnet
mask should be 255.0.0.0; if the IP is 10.1.2.0,
subnet mask should be 255.255.255.0.

Other manuals for Tenda W311R

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Tenda W311R and is the answer not in the manual?

Tenda W311R Specifications

General IconGeneral
Ethernet LANYes
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity11 channels
Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)150 Mbit/s
Bandwidth2.4 GHz
InterfaceLAN, WAN, WLAN
Input voltage110 - 240 V
Dimensions (WxDxH)110.02 x 159.95 x 31 mm
Power requirements9V DC, 1A
USB ports quantity0
Networking featuresEthernet, Fast Ethernet
Maximum data transfer rate0.1 Gbit/s
Supported data transfer rates10/100Mbit/s
WLAN data transfer rates supported11, 54, 150 Mbit/s
DHCP clientNo
Supported network protocolsPPPoE/PPTP/L2TP/DHCP server
Security algorithmsWEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Antennas quantity1
Antenna gain level (max)5 dBi
Ethernet LAN (RJ-45) ports4
Bundled softwareInternet Explorer 5.5 / Firefox 1.0
CertificationFCC, CE, RoHS, WEEE
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)10 - 90 %
LED indicatorsLAN, Link, Power, WAN, WLAN
Weight and Dimensions IconWeight and Dimensions
Weight- g
