Tenma 72-8170 - Controls and Functions; Specifications

Controls and Functions
(1) Zero calibration adjustment
(2) Range selector
(3) 10A input terminal
(4) (+) probe input
(5) (–) probe input
(6) Transistor input terminals
(7) Calibration pushbutton
(8) Indicator pointer
(9) Carry handle/stand
Specifications
Function Measurement Ranges Accuracy Remarks
0.6V, 3.0V, 12V, 60V and 300V ±3% full scale
DCV
1000V ±5% full scale
Input impedance
20K/volt
12V, 30V, 120V, 300V ±4% full scale
ACV
1000V ±5% full scale
Input impedance
9K/volt
120µA, 3mA, 30mA, 300mA ±3% full scale
DCA
10A ±5% full scale
Ohms x1, x100, x1K, x10K ±3% of arc
Continuity Beeps below 100
Battery test
1.5V @ 300mA
9V @ 30mA
Displays
Replace/Good
Operating temperature range: 0~40° C
Relative humidity: 80%
Power source: 1.5V AA (x2), plus 9V (x1)
Fuse: 0.5A fast blow, 5 × 20mm
Dimensions: 6.7" (H) x 4.9" (W) x 1.9" (D)
Included accessories: Test leads, instruction manual
