8
Fix the kickstand to the frame with the 5mm Hex Key; the torque should be 9Nm-12Nm.
Adjust the length of the kickstand with the 4mm Hex Key (it is recommended to adjust
the length of the kickstand to the maximum); the torque should be 5Nm-7Nm.
Use a 4 mm Hex Key to fix the rear mudguard
supports to both sides of the seat stay.
2. Install the rear mudguard and
kickstand
4 mm Hex Key
4 mm Hex Key
5 mm Hex Key
