Ter Welding Multi Synergic 250 - Digital Torch

Push together
Top Button +
Selects between
jobs
Top Button +
Sets the current
(or the voltage in
MIG manual)
Right Button +
Adjusts the arc length
inside the job
Right Button +
Adjust the arc length
in synergic (or the wire
speed in MIG manual)
Bottom Button -
Selects between
jobs
Bottom Button -
Sets the current
(or the voltage in
MIG manual)
Left Button -
Adjusts the arc length
inside the job
Left Button -
Adjust the arc length
in synergic (or the wire
speed in MIG manual)
The digital Torch has two operational modes. SET and JOBS. To switch from on mode to another, Push the Left and Bottom together.
In
JOB mode any adjustment can be done from the front panel and is stored inside the current JOB
MULTI-SYNERGIC - LOGIC TORCH OPERATION
SET MODE
JOB MODE
