• Orient the transmitter and receiver so they are parallel to
each other.
The Bolt Panel Antenna has three 3/8” threaded holes: One on the bottom for mounting the included
light stand adapter or any 3/8” mounting accessory, and one on each side to mount to a yoke mount
bracket assembly.
MOUNTING
• Mount the Panel Antenna vertically, keeping it clear of any obstructions.
• For best results, orient the Panel Antenna so the front
(with the Teradek logo) has a clear line−of−sight to
the transmitter.
DO NOT OVERTIGHTEN SCREWS
INSERTED INTO THE RECEIVER’S 3/8”
THREADED HOLES. Doing so can damage the receiver’s
chassis, voiding the warranty.
CAUTION:
5
