INDEX
INDEX
2
What the load moment indicator does? Pag.
LOAD MONITORING INDICATOR (LMI) FUNCTIONAL DESCRIPTION 3
Which components are included in an LMI?
SYSTEM LAY-OUT AND CONNECTIONS 4 - 7
How is the LMI installed on the machine?
COMPONENTS LOCATION ON THE MACHINE 8
What’s the need of the control panel?
CONTROL PANEL DESCRIPTION 9
What’s does it happen when starting the machine?
SWITCHING THE MACHINE ON 10
Is the control panel informing about safety on the machine?
PANEL MONITORING
– Lifting conditions % and alarms 11
Is the control panel giving useful information to work?
PANEL MONITORING
– Main working data reading on the display 12 , 13
Is the control panel giving useful information to work?
PANEL MONITORING
– Main working data reading through graphics 14
Can the control panel give further useful information regarding the machine?
PANEL SCREENS
– Complementary reading related to the machine functioning 15
How to select the Operating Mode?
SELECTING THE OPERATING MODE
– Operating mode set up 16
How con I select the rope number (tackle) ?
PART OF LINES SETTING UP 17
Can the LMI detect faults?
AUTO-DIAGNOSTIC 18
How the fault shows up?
ALARM CODES AND ACTIONS TO TAKE 19 , 20
Appendix
WORKING SPACE LIMITATION
– i.s.a.c. (interactive space automatic control) 21
– MAX Angle Setting 22
– MAX Height setting 23
– MAX Radius setting 24
– WALL (Working Area Limiting Link) limit setting 25
– SET POINT 1 (ONE) 26
– SET POINT 2 (TWO) 27 , 28
What should be known before starting the machine?
WARNINGS 29 , 30
