Terex Bid-Well 4800 - User Manual

Questions and Answers

J
James PettySep 23, 2025
Why is there speed loss in one direction on my Terex Bid-Well 4800?
- G
  gonzalesbrandySep 23, 2025
  If your Terex Construction Equipment carriage experiences speed and power loss for the carriage travel drive motor when traveling in one direction, but travel in the return direction is normal, it could be due to several reasons: * The clevis end or rear spool stop is unscrewing from the reversing valve spool. Clean the oil from the clevis end threads, assemble, and apply Loctite. * The carriage travel reversing valve is worn or faulty. Replace the valve. * The hydraulic motor is worn or damaged. Replace the motor.
S
Stephanie RiveraAug 23, 2025
What to do if my Terex Construction Equipment has no hydraulic power?
- G
  Gregory BaileyAug 25, 2025
  If your Terex Construction Equipment experiences a loss in speed and/or power, or has no hydraulic power, the hydraulic oil level in the tank may be low. Add hydraulic oil until it is within two inches of the top of the tank.
E
Eric MilesAug 25, 2025
Why is the drag pan leaving an indentation on the Terex Construction Equipment?
- G
  Gregory LarsonAug 26, 2025
  If the drag pan on your Terex Construction Equipment is leaving an indentation on the surface at the curb line or slab edge, it could be due to several reasons: * Too much weight on the drag pan. Remove some or all of the added weight from the pan. * The pan is not being pulled straight. Adjust and hook the chains, ensuring they are hooked the same number of links from the pan. * The pan is being pulled at a point too high. Adjust the height of the hanger frame to approximately 6 inches from the grade.
P
Paul ChenAug 27, 2025
Why is the paving roller on my Terex Construction Equipment noisy?
- R
  Rebecca CherryAug 27, 2025
  If the paving roller on your Terex Construction Equipment slows or stops under load and there is excessive bearing noise or heat, the paving roller shaft bearings may be damaged. Replace the bearings to resolve this issue.
M
Miss Bridget RobertsAug 27, 2025
Why does the finish from the rollers on my Terex Bid-Well 4800 Construction Equipment look like a washboard?
- T
  Tracy FosterAug 28, 2025
  If the finish coming from the rollers on your Terex Construction Equipment looks like a washboard, with possible vibration on the lower paving carriage, the auger shaft may be bent, or the augers may be out of balance. Alternatively, one or more slide blocks on the lower carriage frame may not be contacting the skew ring on the upper carriage. Remove the augers and inspect the shafts for straightness. Attach the augers and check for visual imbalance. Tighten the center pivot bolt so the slide blocks contact the skew ring, still allowing skewing if a skew cylinder is used.
T
teresa82Sep 18, 2025
What to do if the Terex Bid-Well 4800 carriage doesn’t reverse direction?
- X
  xolsenSep 18, 2025
  If the carriage on your Terex Construction Equipment doesn’t reverse direction while in the pave position and the machine continues to travel, the reversing valve on the controller may not be completely shifted. Check the adjustment of the Adjustable Linkage Assembly, using the formula provided with Figure 2.
K
Kyle CarterSep 15, 2025
Why does the carriage on my Terex Bid-Well 4800 only work in Non-Reversing Mode?
- J
  James ReynoldsSep 15, 2025
  If the carriage on your Terex Construction Equipment only works in Non-Reversing Mode and will not go into Auto-Reversing Mode after shifting the selector handle, both the MV1 and MV2 Cartridge Valves may be stuck and not shifting. Replace both cartridges.
M
Michael KelleySep 16, 2025
Why does the carriage on my Terex Bid-Well 4800 Construction Equipment only work in Auto-Reversing Mode?
- F
  felicia43Sep 17, 2025
  If the carriage on your Terex Construction Equipment only works in Auto-Reversing Mode and will not switch to Non-Reversing Mode after shifting the selector handle, both the MV1 and MV2 Cartridge Valves may be stuck. Replace both cartridges.
A
Alexander HernandezSep 6, 2025
Why is the paving roller on my Terex Bid-Well 4800 not skewing properly?
- M
  Michael ThomasSep 6, 2025
  If the paving roller on your Terex Construction Equipment does not skew in the proper direction, but is spinning correctly, the hydraulic lines to the hydraulic skew cylinder may be improperly connected. Reverse the hoses leading to the hydraulic skew cylinder.
M
Mark ThomasSep 3, 2025
Why does the paving roller on my Terex Bid-Well 4800 stop under load?
- A
  Andrew PriceSep 4, 2025
  If the paving roller on your Terex Construction Equipment does not operate or stops under load, but the relief valve is okay and the augers operate normally, the roller motor may be damaged or worn, or the reversing valve may have developed internal damage. Replace the motor and the reversing valve.

Summary

SECTION I: INTRODUCTION

BIDWELL WARRANTY

Details the warranty terms for products against defects in workmanship and materials.

MACHINE SPECIFICATIONS

Outlines the technical specifications of the Model 4800 Concrete Paver.

MACHINE WEIGHTS

Provides approximate weights for the machine, including components and optional accessories.

OPERATOR QUALIFICATION

Lists minimum qualifications, physical requirements, and necessary skills for operators.

OPERATOR CONDUCT

Outlines expected behavior, responsibilities, and safety practices for machine operators.

SAFETY

GENERAL SAFETY PRECAUTIONS

Essential safety practices for operating, maintaining, and working around the paver.

HYDRAULIC SYSTEMS PRECAUTIONS

Safety guidelines for working with the paver's high-pressure hydraulic systems.

REFUELING PRECAUTIONS

Safety instructions for refueling the machine to prevent fire and explosion hazards.

SAFETY DECALS

Importance of keeping safety decals clean, legible, and replacing missing ones.

BATTERY PRECAUTIONS

Safety measures related to the machine's battery system to avoid electrical hazards.

TRANSPORT PRECAUTIONS

Guidelines for safely lifting and transporting the paving machine.

STORAGE PRECAUTIONS

Recommendations for storing the paver to ensure safety and preserve its condition.

SECTION II: COMPONENTS & CONTROLS

PAVER COMPONENTS

Detailed description of the paver's main structural and functional parts.

PAVER CONTROLS

Explanation of the operator's control console functions and operation.

SECTION III: SETUP - OPERATION - MAINTENANCE

LIFTING THE MACHINE

Procedures and warnings for safely lifting the paving machine.

LOADING THE MACHINE

Step-by-step instructions for loading the machine onto a flatbed truck.

TOWING THE MACHINE

Guidelines and warnings for towing the paver safely.

SCREED RAIL AND PAVING FORMS

Importance and setup of screed rails and paving forms for profile accuracy.

MACHINE SETUP

Instructions for assembling the paver and preparing it for operation.

PAVING THIN BONDED CONCRETE OVERLAYS

Specific considerations for paving thin bonded concrete overlays.

DAILY ROUTINE SERVICE

Daily checks and basic service tasks for the paver.

MACHINE ENGINES

Information on the paver's engines, including maintenance and fuel types.

HYDRAULIC OIL AND OIL FILTERS

Procedures for checking hydraulic oil levels and replacing filters.

CONTROLLER ADJUSTMENT

Instructions for adjusting the machine's controller for proper operation.

TROUBLE SHOOTING

Common issues, causes, and remedies for paver operational problems.

SECTION IV: STANDARD PARTS BOOK

GROUP 1

Parts breakdown and diagrams for Group 1 components of the paver.

GROUP 2

Parts breakdown and diagrams for Group 2 components of the paver.

SECTION V: OPTION PARTS BOOK

POPULAR OPTIONS with illustrations

List and diagrams of common optional equipment for the paver.

MISCELLANEOUS options

Optional equipment not illustrated, requiring service department contact.
