It’s a system including sensors able to detect lifted load,
boom position, a main unit and a control panel situated
inside at the cabin.
SYSTEM LAY
SYSTEM LAY
-
-
OUT MEGAMAC.HC212
OUT MEGAMAC.HC212
AND CONNECTIONS
AND CONNECTIONS
Which components are included in an LMI?
6
INPUT OUTPUT SIGNALS
AND EXTERNAL SUPPLY
J1
PG1
PG2
PG3 PG4 PG5
PG6
1
6
4
2
7
LOW CHAMBER (BOTTOM SIDE)
HIGH CHAMBER (ROD SIDE)
5
B
A
8
8
6
3
A2B
Ref. Description Code
1 Main unit U2MIC-X/XX
2 Control panel CMC100-XX/XX
3 Cable reel ACT11AS100/XX
4 Cable reel AC MCP214A/3P
5 Pressure transducer Y11 4745-350
6 Cable CV 4x0.5+SCH
7 Cable CV ATG12/XX
8
9
Cable
A-2-B Switch
CV 8x0.35+SCH
A2B N2
9
