COMPONENTS LOCATION ON THE MACHINE
COMPONENTS LOCATION ON THE MACHINE
How is the LMI installed on the machine?
The sensors are positioned on the boom and cylinders in
order to detect data when working, while the main unit and
the control panel are located inside the cabin.
Control Panel :
into the cabin
Main Unit
Nr.2 Pressure
Transducers:
On the lifting cylinder.
Rod and bottom side
Length sensor
Used in case of boom
indipendent sections
Length/Angle sensor
