Work Area Safety
Maximum capacity - GS-4390
Maximum occupants 7
Models with one platform extension
Platform retracted 1500 lbs 680 kg
Platform only 1000 lbs 454 kg
Extension only 500 lbs 227 kg
Extension only Platform only
500 lbs / 227 kg 1000 lbs / 454 kg
Models with two platform extensions
Platform retracted 1500 lbs 680 kg
Platform with one 1000 lbs 454 kg
extension out
Platform with two 500 lbs 227 kg
extensions out
Extension only 500 lbs 227 kg
Extension only Platform only Extension only
500 lbs / 227 kg 500 lbs / 227 kg 500 lbs / 227 kg
Maximum capacity – GS-5390
Maximum occupants - ANSI & CSA 6
Maximum occupants - Australia 4
Models with one platform extension
Platform 1500 lbs 680 kg
retracted
Platform only 1000 lbs 454 kg
Extension only 500 lbs 227 kg
Extension only Platform only
500 lbs / 227 kg 1000 lbs / 454 kg
Models with two platform extensions
Platform retracted 1500 lbs 680 kg
Platform with one 1000 lbs 454 kg
extension out
Platform with two 500 lbs 227 kg
extensions out
Each extension 500 lbs 227 kg
only
Extension only Platform only Extension only
500 lbs / 227 kg 500 lbs / 227 kg 500 lbs / 227 kg
