Fourth Edition • Fourth Printing Operator's Manual
GS-3384
Height, working maximum 39 ft 11.9 m
Height, platform maximum 33 ft 10.1 m
Height, stowed maximum, rails up 105.5 in 2.7 m
Height, stowed maximum, 78.75 in 2.0 m
rails lowered
Width, standard tires 84 in 2.1 m
Length, platform retracted 155.25 in 3.9 m
Models with one extension deck
Length, platform extended 212.5 in 5.4 m
Models with one extension deck
Length, platform retracted 156.5 in 3.9 m
Models with two extension decks
Length, platform extended 258.5 in 6.6 m
Models with two extension decks
Length, platform retracted 192 in 4.9 m
Models with outriggers
Models with two super decks
Length, platform extended 290.5 in 7.4 m
Models with two super decks
Maximum load capacity 2500 lbs 1134 kg
Maximum wind speed 28 mph 12.5 m/s
Wheelbase 113.5 in 2.9 m
Turning radius (outside) 234 in 5.9 m
Turning radius (inside) 121.5 in 3.1 m
Ground clearance 13 in 33 cm
Weight
(Machine weights vary with option configurations.
See serial label for specific machine weight.)
Platform dimensions
Platform length x width 150 in x 72 in 3.8 x 1.8 cm
Platform extension length 60 in 1.5 m
Specifications
Drive speeds
Stowed, maximum 4 mph 6.4 km/h
Platform raised, 0.7 mph 1.1 km/h
maximum 40 ft / 39 sec 12.2 m / 39 sec
Controls Proportional
AC outlet in platform Standard
Maximum hydraulic 3500 psi 241.3 bar
pressure (functions)
Tire size 10-16.5 NHS
Tire size, high flotation 33/16LL500, 10 ply
Maximum side slope rating, stowed 50% (26°)
position
Maximum slope rating, stowed 50% (26°)
position
Note: Slope rating is subject to ground conditions and
adequate traction.
Floor loading information
Tire load maximum 4689 lbs 2127 kg
Outrigger load, maximum 4689 lbs 2127 kg
(If equipped)
Tire contact pressure 129 psi 9.03 kg/cm
2
886 kPa
Occupied floor pressure 177 psf 864 kg/m
2
8.49 kPa
Note: Floor loading information is approximate and does
not incorporate different option configurations. It should
be used only with adequate safety factors.
Continuous improvement of our products is a Genie
policy. Product specifications are subject to change
without notice or obligation.
Part No. 133564 GS-3384 • GS-3390• GS-4390• GS-5390 51
