Operator's Manual Fourth Edition • Fourth Printing
Inspections
Decals Inspection with Words
Use the appropriate inspection to verify that all
decals are legible and in place.
Below is a numerical list with quantities
and descriptions.
Part No. Decal Description Qty
25994 Notice – Component Damage Hazard 1
28158 Label – Unleaded 1
28159 Label – Diesel 1
28160 Label – Liquid Petroleum Gas 1
28174 Label – Power to Platform, 230V 3
28175 Warning – Compartment Access 1
28176 Label – Missing Manuals 1
28235 Label – Power to Platform, 115V 3
28236 Warning – Improper Operation 1
31060 Danger – Tip-over Hazard, Limit Switch 1
40434 Label – Lanyard Anchorage Point 8
43618 Label – Directional Arrows 1
43619 Label – Safety Arm 1
44255 Danger – Crushing Hazard 4
44736 Danger – Tip-over Hazard, Tilt Alarm 1
44981 Label – Air Line to Platform 2
52431 Label – Ground Control Panel 1
52475 Label – Transport Tie-down 4
52494 Caution – Crushing Hazard, Rails 1
52967 Cosmetic – 4 x 4 2
62748 Cosmetic – Genie GS-4390 2
65061 Cosmetic – Genie GS-5390 2
65063 Notice – Tire Specifications 4
65281 Notice – Max Side Force, ANSI & CSA 2
GS-4390
72186 Warning – Crushing Hazard, Outriggers 4
72816 Notice – Maximum Capacity, 1500 lbs / 2
600 kg
72818 Label – Test Mode Switch 1
72847 Notice – Tire Specifications, High 4
Floatation
72853 Danger – Improper Use Hazard 1
72860 Notice – Max. Side Force, ANSI & CSA, 2
GS-5390
72868 Label – Engine Tray Prop 1
Part No. Decal Description Qty
82210 Cosmetic – Genie GS-3384 2
82211 Notice – Max. Side Force, ANSI & CSA, 2
GS-3384, GS-3390
82213 Notice – Maximum Capacity, 2500 lbs / 2
1134 kg
82215 Notice – Tire Specifications 4
82224 Label – HOT, Ford Tier II Engines 1
82366 Label – Chevron Rando 1
82417 Platform Control Panel 1
82418 Ground Control Panel 1
82557 Label – Platform Controls Location 1
82558 Warning – Skin Injection Hazard 1
82559 Instructions – Annual Inspection 1
82561 Danger – Crushing Hazard 2
82757 Danger – Outrigger Safety and 1
Instructions
82793 Instructions – Operating Instructions, 1
Ground
82798 Ground Control Panel 1
82809 Label – Wheel Load, GS-3384 4
82824 Label – Wheel Load, GS-3390, GS-4390 4
82825 Label – Wheel Load, GS-5390 4
97548 Instructions – Deutz Engine 1
Specifications (F3L 2011 & D2011 L03i)
Tier II
97602 Warning – Explosion Hazard 1
97753 Cosmetic – Genie GS-3390 2
97763 Notice – Max. Side Force, AUS, 2
GS-3384, GS-3390, GS-4390
97764 Notice – Max. Side Force, AUS, 2
GS-5390
114169 Instructions – Ford Engine Specifications 1
(DSG-423)
114258 Danger – Explosion Hazard 1
114385 Danger – Electrocution Hazard 2
114386 Danger – General Safety Rules 1
Continued on next page.
32 GS-3384 • GS-3390• GS-4390• GS-5390 Part No. 133564
