Operator's Manual Fourth Edition • Fourth Printing
Inspections
Decals Inspection with Symbols
Use the appropriate inspection to verify that all
decals are legible and in place.
Below is a numerical list with quantities
and descriptions.
Part No. Decal Description Qty
28158 Label – Unleaded 1
28159 Label – Diesel 1
28160 Label – Liquid Petroleum Gas 1
(1 additional with extra LPG tank option)
28174 Label – Power to Platform, 230V 3
28235 Label – Power to Platform, 115V 3
40434 Label – Lanyard Anchorage Point 8
43618 Label – Directional Arrows 1
44981 Label – Air Line to Platform 2
52475 Label – Transport Tie Down 4
52967 Cosmetic – 4 x 4 2
62748 Cosmetic – Genie GS-4390 2
65061 Cosmetic – Genie GS-5390 2
72868 Label – Engine Tray Prop 1
82210 Cosmetic – Genie GS-3384 2
82417 Platform Control Panel 1
82418 Ground Control Panel 1
82473 Label – Compartment Access 2
82474 Label – Use Safety Chock 2
82475 Label – Crushing Hazard, Outriggers 4
82476 Label – Electrocution Hazard 2
82481 Label – Battery/Charger Safety 1
82487 Label – Read the Manual 2
82560 Label – Skin Injection Hazard 1
82562 Label – Crushing Hazard 4
82756 Label – Tire Pressure, High Floatation 4
82798 Ground Control Panel 1
82924 Label – Shut-off Valves 1
82808 Label – Maximum Capacity, 1134 kg 2
82809 Label – Wheel Load, GS-3384 4
82810 Danger – Max. Side Force, 1557 N, 2
ANSI
82812 Label – Read the Service Manual 1
82819 Danger – Max. Side Force, 1335 N, 2
GS-5390, ANSII
Part No. Decal Description Qty
82820 Danger – Max. Capacity, 680 kg, 2
GS-4390, ANSI
82822 Danger – Max. Capacity, 680 kg, 2
GS-5390, ANSI
82824 Label – Wheel Load, GS-3390, GS-4390 4
82825 Label – Wheel Load, GS-5390 4
97709 Label – Hot 1
97719 Label – Safety Arm 1
97753 Cosmetic – Genie GS-3390 1
114251 Label – Explosion Hazard 1
114371 Label – Outrigger Safety 1
114337 Label – Tip-over Hazard, Limit Switch 1
114338 Label – Tip-over Hazard, Tilt Alarm 1
133269 Label – Outrigger Load, GS-3384 4
133270 Label – Outrigger Load, GS-3390 4
133271 Label – Outrigger Load, GS-4390 4
133272 Label – Outrigger Load, GS-5390 4
133537 Label – Crushing Hazard 1
215526 Label – Belt Routing (MSG-425) 1
36 GS-3384 • GS-3390• GS-4390• GS-5390 Part No. 133564
