Operator's Manual
Operating Instructions
Engine Idle Select
Select the engine idle (rpm) by pressing the idle
select button. There are three settings for engine
idle:
Indicator light off: low idle
Indicator light blinking: high idle
activated by any function enable
button
Indicator light on: high idle
Operation from Platform
1 Turn the key switch to platform control.
2 Pull out both ground and platform red
Emergency Stop buttons to the on position.
3 Start the engine.
To Position Platform
1 Push and hold the lift function
enable button.
2 Activate the up/down rocker switch
in the desired direction.
To Steer
1 Press and hold the function enable switch
on the control handle.
2 Turn the steer wheels with the thumb rocker
switch located on the top of the control handle.
Fourth Edition • Fourth Printing
To Drive
1 Press and hold the function enable switch
on the control handle.
2 Increase speed: Slowly move the
control handle off center.
Decrease speed: Slowly move the
control handle toward center.
Stop: Return the control handle to center
or release the function enable switch.
Use the color-coded direction arrows on the
platform controls and the drive chassis to
identify the direction the machine will travel.
Machine travel speed is restricted when
the platform is raised.
Drive Select Button
Machine on incline symbol: Low
range operation for inclines.
Indicator Light On Red
If the indicator light is on red, push
in and pull out the red Emergency
Stop button to reset the system.
If the light stays red, tag and
remove the machine from service.
40 GS-3384 • GS-3390• GS-4390• GS-5390 Part No. 133564
