First Edition • Second Printing Operator's Manual
Inspections
Part No. 1308591GT GS
™
-1432m • GS
™
-1932m • GS
™
-1932m Lite 31
Test Auxiliary Lowering
15 Activate the up function by pressing the lift
enable button and platform up button, and
raise the platform approximately 2 ft. / 60 cm.
16 Pull the auxiliary lowering knob, located at the
rear of the bottom link.
Result: The platform should lower. The
descent alarm will not sound.
Test the Tilt Sensor Operation
17 Press the ground control down button
(button 3)
Result: The ground control LCD screen will
display the status of the tilt sensor.
18 Turn the key switch to platform control.
At the Platform Controls
Test Emergency Stop
19 Push in the platform red Emergency Stop
button to the off position.
Result: No functions should operate.
Test the Alarm for Tilt Sensor
20 Pull out the red Emergency Stop button to the
on position.
21 Press the horn button.
Result: The platform alarm, chassis alarm, and
automotive horn (if equipped) should sound.
Test the Function Enable Switch and the
Up/Down Functions
22 Do not hold the function enable switch on the
control handle.
23 Slowly move the control handle in the direction
indicated by the blue arrow, then in the
direction indicated by the yellow arrow.
Result: No functions should operate.
24 Press the lift function button.
25 Wait seven seconds for the lift function to time
out.
26 Slowly move the control handle in the direction
indicated by the blue arrow, then in the
direction indicated by the yellow arrow.
Result: The lift function should not operate.
To Next Page
