Terex GS32MT-101 User Manual

First Edition • Second Printing Operator's Manual
Specifications
Part No. 1308591GT GS
™
-1432m • GS
™
-1932m • GS
™
-1932m Lite 65
Model
GS-1932m
Height, working outdoor
21 ft 0 in
6.57 m
Height, platform outdoor
15 ft 0 in
4.57 m
Height, working indoor
24 ft 2 in
7.55 m
Height, platform indoor
18 ft 2 in
5.55 m
Height, stowed maximum, rails up
6 ft 5 in
1.97 m
Height, stowed maximum,
rails folded
5 ft 2 in
1.58 m
Platform height, stowed maximum
2 ft 10 in
0.87 m
Height, guard rails
3 ft 7 in
1.10 m
Width
32 in
0.81 m
Length, stowed
4 ft 7 in
1.40 m
Length, platform extended
6 ft 7 in
2 m
Platform extension length
24 in
0.6 m
Platform dimensions (length x
width)
4 ft 7 in x
30 in
1.40 m x
0.77 m
Maximum load capacity
500 lbs
227 kg
Maximum wind speed, outdoors
28 mph
12.5 m/s
Maximum wind speed, indoors
0 mph
0 m/s
Wheelbase
3 ft 8 in
1.12 m
Turning radius (outside)
4 ft 6 in
1.37 m
Turning radius (inside)
0 in
0 cm
Ground clearance
2.8 in
7 cm
Ground clearance
Pothole guards deployed
0.75 in
2. cm
Weight
2600 lbs
1179 kg
(Machine weights vary with option configurations. See
serial label for specific machine weight.)
Power source
2 Batteries, 12V 115AH
System voltage
24V
Maximum hydraulic pressure
(functions)
2400 psi
165.5 bar
Tire size
10 x 3 in
25 x 8 cm
Total vibration value to which the hand/arm system is
subjected does not exceed 2.5 m/s
2
.
Highest root mean square value of weighted
acceleration to which the whole body is subjected does
not exceed 1.6 ft/s
2
or 0.5 m/s
2
.
Ambient operating temperature
Minimum
-20°F
-29°C
Maximum
120°F
49°C
Airborne noise emissions
Sound pressure level at ground
workstation
<70 dBA
Sound pressure level at platform
workstation
<70 dBA
Maximum slope rating, stowed position
25% (14°)
Maximum side slope rating, stowed
position
25% (14°)
Note: Slope rating is subject to ground conditions with
one person in the platform and adequate traction.
Additional platform weight may reduce slope rating.
Drive speeds
Stowed, maximum
2.5 mph
4.0 km/h
Platform raised,
maximum
0.5 mph
40 ft/55 sec
0.8 km/h
12.2 m/55 sec
Floor loading information, GS-1932m
Tire load maximum
1257 lbs
570 kg
Tire contact pressure
164 psi
10.13 kg/cm
2
1131 kPa
Occupied floor pressure
254 psf
1238 kg/m
2
12.16 kPa
Note: Floor loading information is approximate and
does not incorporate different option configurations. It
should be used only with adequate safety factors.
Continuous improvement of our products is a Genie
policy. Product specifications are subject to change
without notice or obligation.
