Terex TL120 - Dimensions and Weights

31
Operating Instructions Wheel Loader TL120
Technical Specifications 3
3.12 Dimensions and weights
Dimensions and weights
Operating weight, standard equipment
1
approx. 6800 kg
Total length, standard bucket on ground 5635 mm
Total width 2100 mm
Total height (cab roof) 2780 mm
Wheel base 2290 mm
Tire tread with, FR / RR 1640 mm
Rear overhang angle 35°
Ground clearance below propeller shaft 460 mm
Turning radius at outside edge of bucket in transport position 4640 mm
Turning radius at inside edge of tires 2115 mm
Table 15 Dimensions and weights - Specifications refer to general-purpose bucket and 405/70 R 20 tires
1
In compliance with ISO 6016
Front loader installation
Width of bucket 2100 mm
Capacity to DIN/ISO 7546 (max. density = 1.8 t/m
3
) approx. 1.2 m³
Payload in bucket 2160 kg
Dump height at 45° dump angle approx. 2750 mm
Dump reach at max. dump height approx. 800 mm
Max. bucket hinge pin height approx. 3530 mm
Tilt-back angle 50°
Dump angle at max. dump height 45°
Digging depth, horizontal bucket approx. 90 mm
Lift capacity at ground level
1
approx. 71000 N
Ripping force at cutting edge of bucket
1
approx. 59000 N
Tipping load, straight
1
approx. 4900 kg
Tipping load, articulated
1
approx. 4330 kg
Work cycle times, "Lift" 5.8 sec.
"Lower" 3.7 sec.
Dumping in uppermost position "In" 1.3 sec.
"Out" 1.5 sec.
Table 16 Dimensions and weights - Specifications refer to general-purpose bucket and 405/70 R 20 tires -
Stability conforms to DIN 24094
1
In compliance with ISO 8313
Bucket Width
mm
Capacity, heaped
m
3
Max. density (γ)
t/m
3
General-purpose bucket 2100 1.2 1.8
Multi-purpose bucket 2100 1.05 1.6
Earth bucket 2100 1.35 1.6
Light-material bucket 2100 1.55 1.2
Super light-material bucket 2200 1.8 0.8
Side-dump bucket 2100 0.85 1.8
High-tip bucket 2100 1.2 1.2
High-tip bucket 2200 1.8 0.6
Compost bucket 2100 1.2 1.2
Table 17 Bucket dimensions
