SYSTEM SCHEMATICS

2-5

Page 3

ML50-30 MAINTENANCE LIFT

TESCO EQUIPMENT LLC

ITE

QTY TESCO NO PART NUMBER/DESCRIPTION NOTE

1 1 326-9110-490 • PUMP, 19 GPM

TR5012112NFHXNFXB

• HYDRAULIC POWER MODULE

1 HYMS20046 •• CARTRIDGE, Systm Relief Valve

1 HYMS20047 •• CARTRIDGE, Stabilizer Flow Control

Valve

1 HYMS20049 •• CARTRIDGE, Handpump Valve

1 HYMA10008 •• MANIFOLD, W/Return Filter Provision

1 HYVA10245 •• CARTRIDGE, Pressure Reducing

500-3000 psi

4 HYMS20042 •• COIL, D05 12VDC Lift & Stabilizer

2 HYMS20041 •• VALVE, D05 3 Pos./4 Way Lift & Stabilizer

1 HYMS20055 •• MANIFOLD, Sandwitch, Port Relief

1 HYVA10247 •• CARTRIDGE, Port Relief

1 HYMS20048 •• CARTRIDGE, Lift Flow Control Valve

1 HYMS20045 •• GAUGE, 0-3000 PSI

1 HYMS20052 •• VALVE, Check, Inlet

1 HYFI10017 •• FILTER ELEMENT, Return

1 HYMS20051 •• PUMP, AUXILIARY 12VDC

1 HYVA10273 •• SANDWICH VALVE, Relief Lift

1 HYVA10149 •• CARTRIDGE, PBU Valve

5 4 HYVA10120 • CARTRIDGE, Counter Balance Valve

4 HYVA10121 • BODY, Counter Balance Valve

9 4 HYCY10027 • CYLINDER, Double Acting Stabilizer

11 2 HYCY10005 • CYLINDER, Single Acting Lift

12 2 HYCY10006 • CYLINDER, Single Acting Lift

Apr. 17

Property of American Airlines
