MAINTENANCE
2-1
Page 4
TESCO EQUIPMENT LLC
ML50-30 MAINTENANCE LIFT
NOTE: The scissors lift must be raised to access the grease points. Make sure to put maintenance
prop up.
NOTE: Check at intervals listed and lubricate as required. In unusual weather conditions, check at
more frequent intervals.
GREASE POINTS
ITEM COMPONENT
TOTAL
FITTINGS
INTERVAL
1 Scissor pivot pins (Upper/Middle/Lower) 12 6 mos.
2 Scissor Arm End Pins 4 6 mos.
3 Scissor roller (Upper/Lower) 8 6 mos.
4 Traversing roller pins 4 6 mos.
5 Lift cylinder (Upper/Lower) 8 6 mos.
6 Traversing cylinder rod ends 2 6 mos.
7 Booster arm pivot 1 6 mos.
8 Stabilizers 16 6 mos.
9 Roller Tracks 3 mos.
GREASE
Mar. 17
