Tescom DS3100 - UPS Front Panel Menu Navigation; Core Menu Sections Overview

15
Main menu (Level 1)
Men
u
Usage
1
STATUS
→ Enter Status menu
2
MEASUREMENTS
→ Enter Measurements menu
3
ALARM LOGS
→ Enter Alarm logs menu
4
INFORMATION
→ Enter Information menu
5
OPTIONS
→ Enter Options menu
6
COMMAND
→ Enter Command menu
7
TIME
→ Enter Time menu
8
SERVİCE
→ Enter Service menu
9
PASSWORD
→ Enter Password screen
10
ADJUST
→ Enter Adjust menu
Goto 1
Sub menus (Level 2)
Level
1
Level 2
Page
Level 3
STATUS Status of the UPS
MEASUREMENTS INPUT Input measurements
BYPASS Bypass measurements
INVERTER Inverter measurements
OUTPUT Output measurements
DC DC measurements
GENERAL General measurements
ENTER - EXIT
ALARM LOGS
UPS LOG RECORD Page1
ENTER CLEAR LOG Page1
ENTER - EXIT
INFORMATION RS232 Comm 1:-- 2:-- Page1
Maximum UPS power Page1
Nominal voltage and frequency Page1
Inverter firmware version Page2
PFC firmware version Page2
Panel firmware version Page2
UPS Model Page3
Communication protocol Page3
Chassis nr Page3
ENTER - EXIT
OPTIONS LCD OPTIONS LCD panel options
COMM.OPTIONS Communication options
ALARM OPTIONS Alarm options
BYPASS OPTIONS Bypass options
ENTER - EXIT
COMMAND By-pass transfer Page1
Boost charge start Page1
Short battery test start Page1
Relay check Page2
Dialup modem programming Page2
Alarm sound ON/OFF Page3
Warning sound interval Page3
ENTER - EXIT
TIME Current time Page1
Current date Page1
Set hour Page2
Set minute Page2
Set day Page3
