3.2.1 MEASUREMENTS menu
All mesasured values of the UPS can be monitored from this menu.
Use up and down buttons to move on submenu
MEASUREMENTS / INPUT (Level 2)
All rectifier input measurements are located in this menu, use up and down buttons to move on submenu
MEASUREMENTS
/
INPUT
Page 1 (Level 3)
P-N L1 L2 L3 Page header
Vinp: 221/222/223 V Phase to neutral measured AC input voltages
Iinp: 000/000/000 A Measured RMS AC input phase currents
…………………………….. Current alarm messages
Up previous page ,down next page
MEASUREMENTS
/
INPUT
Page 2 (Level 3)
P-P L13 L21 L32 Page header
Vinp: 381/382/383 V Phase to phase measured AC input voltages
Finp: 49.6 Hz Measured rectifier input frequency
…………………………….. Current alarm messages
Up previous page ,down next page
MEASUREMENTS
/
INPUT
Page 3 (Level 3)
ENTER - EXIT ENTER exit to upper menu
…………………………….. Current alarm messages
Up previous page, down next page
MEASUREMENTS / BYPASS (Level 2)
All by-pass input measurements are located in this menu, use up and down buttons to move on submenu
MEASUREMENTS
/
BYPASS
Page 1 (Level 3)
P-N L1 L2 L3 Page header
Vbyp: 221/222/223 V Phase to neutral measured AC bypass input voltages
OK OK -- Bypass voltage status
…………………………….. Current alarm messages
Up previous page, down next page
MEASUREMENTS
/
BYPASS
Page 2(Level 3)
P-P L13 L21 L32 Page header
Vbyp: 381/382/383 V Phase to phase measured AC bypass input voltages
Fbyp: OK / 50.0 Hz Measured bypass input frequency
…………………………….. Current alarm messages
Up previous page, down next page
MEASUREMENTS
/
BYPASS
Page 3(Level 3)
ENTER - EXIT ENTER exit to upper menu
…………………………….. Current alarm messages
Up previous page, down next page
