3.2.2 ALARM LOGS MENU
Use this menu to see the alarm log records
ALARM
LOGS
Page 1
(
Level
2)
UPS LOG RECORD Page header
>001>081110 14:33:26 Event no ,date and time (left and right buttons move)
ENTER CLEAR LOG ENTER buton clears all log memory
…………………………….. Current alarm messages
Up upper line, down next line
ALARM
LOGS
Page 2
(
Level
2)
ENTER - EXIT ENTER exit to upper menu
…………………………….. Current alarm messages
Up previous page, down next page
3.2.3 INFORMATION MENU
Some usefull informations are located in this menu , use up and down buttons to move on submenu
INFORMATION MENU
Page 1
(
Level
2)
RS232 Comm: 1:-- 2-- RS232 activity indicator for com1 and com2
MAX Power: 60000 VA Maximum ups output power as VA
Nom:220/050 220/050 Nominal input, output voltage and frequency
…………………………….. Current alarm messages
Up previous page, down next page
INFORMATION MENU
Page 2
(
Level
2)
Inv version: 00001 Inverter module firmware version
Pfc version:00001 PFC rectifier module firmware version
Lcd version:00001 Front panel modul firmware version
…………………………….. Current alarm messages
Up previous page, down next page
INFORMATION MENU
Page 3
(
Level
2)
Model:CL360D Model name of the UPS
Protocol:TX301 Communication protocol version
Chassis nr: 123456 UPS chassis nr
…………………………….. Current alarm messages
Up previous page, down next page
INFORMATION MENU
Page 4
(
Level
2)
ENTER - EXIT ENTER exit to upper menu
…………………………….. Current alarm messages
Up previous page, down next page
