3.2.4 OPTIONS MENU
Use up and down buttons to move cursor on submenu at the end of page you move to next page. Menu
has 3 level structure, if user password is enabled some parameters requires user password.
Level 3 LCD panel options group
Panel language selection Page1
Button click ON/OFF Page1
LCD backlight brigthness Page2
Backlight delay Page2
Backlight dim.delay Page2
ENTER - EXIT Page3
OPTIONS /
LCD
OPTIONS
Page 1 (Level 3)
>LANGUAGE:ENGLISH
Left and right change panel language
(P3330)
CLICK: ON/OFF Left and right buton click sound ON/OFF
…………………………….. Current alarm messages
Up upper line, down next line ,(+) or (-) options ,ENTER select an option
OPTIONS / LCD OPTIONS
Page 2 (Level 3)
>BACKLIGHT:XXXXXXXXX Left and right LCD backlight brightness adjust
BL DELAY:CLOSED Backlight delay
BL DIM:CLOSED Back light half option selection
…………………………….. Current alarm messages
Up upper line, down next line ,(+) or (-) options ,ENTER select an option
OPTIONS / LCD OPTIONS
Page 3 (Level 3)
ENTER - EXIT ENTER exit to upper menu
…………………………….. Current alarm messages
Up previous page, down next page
Level 3 – Communication options
Remote control ON/OFF Page1
COM2 port function Page1
SNMP internal/external Page1
Relay 1 function selection Page2
Relay 2 function selection Page2
Relay 3 function selection Page2
Relay 4 function selection Page3
Relay 5 function selection Page3 Optional
Relay 6 function selection Page3 Optional
Relay 7 function selection Page4 Optional
Relay 8 function selection Page4 Optional
Relay 9 function selection Page4 Optional
Relay 10 function selection Page5 Optional
Relay 11 function selection Page5 Optional
Relay 12 function selection Page5 Optional
REPO input ON/OFF Page6
ENTER - EXIT Page7
