22
OPTIONS / COMMUNICATION OPTIONS
Page 1 (Level 3)
REMOTE CNTRL: ON/OFF Left and right remote control ON/OFF
>COM2:SERVICE PORT Com 2 serial port function selection
SNMP : INTERNAL/EXTERNAL SNMP adaptor location
…………………………….. Current alarm messages
Up upper line, down next line ,(+) or (-) options ,ENTER select an option
OPTIONS / COMMUNICATION OPTIONS
Page 2 (Level 3)
>RELAY1: Left and right buton relay function selection
RELAY 2: Left and right buton relay function selection
RELAY 3: Left and right buton relay function selection
…………………………….. Current alarm messages
Up upper line, down next line ,(+) or (-) options, ENTER select an option
OPTIONS / COMMUNICATION OPTIONS
Page 3 (Level 3)
> RELAY 4: Left and right buton relay function selection
RELAY 5: Left and right buton relay function selection (option)
RELAY 6: Left and right buton relay function selection (option)
…………………………….. Current alarm messages
Up upper line, down next line ,(+) or (-) options, ENTER select an option
OPTIONS / COMMUNICATION OPTIONS
Page 4 (Level 3)
> RELAY 7: Left and right buton relay function selection (option)
RELAY 8: Left and right buton relay function selection (option)
RELAY 9: Left and right buton relay function selection (option)
…………………………….. Current alarm messages
Up upper line, down next line ,(+) or (-) options, ENTER select an option
OPTIONS / COMMUNICATION OPTIONS
Page 5 (Level 3)
> RELAY 10: Left and right buton relay function selection (option)
RELAY 11: Left and right buton relay function selection (option)
RELAY 12: Left and right buton relay function selection (option)
…………………………….. Current alarm messages
Up upper line, down next line ,(+) or (-) options, ENTER select an option
OPTIONS / COMMUNICATION OPTIONS
Page 6 (Level 3)
REPO : ON / OFF Emergency stop input enabled or disabled
…………………………….. Current alarm messages
Up upper line, down next line ,(+) or (-) options, ENTER select an option
OPTI
ONS / COMMUNICATION OPTIONS
Page 7 (Level 3)
ENTER - EXIT ENTER exit to upper menu
…………………………….. Current alarm messages
Up previous page, down next page
Level 3 Alarm options
Warning beep interval Page1
Warning log ON/OFF Page1
Status log ON/OFF Page1
ALF restart ON/OFF Page2
ENTER - EXIT Sayfa3
