27
R24 WAITING DC BUS Warning
Rectifier is waiting DC BUS to raise for startup
R25 BATTERY FAILURE Warning
Battery test failed
R26 BATT TEMP SENSOR Warning
Battery temperature sensor is defected or not connected
R27 BATT TEMP HIGH Warning
Battery ambient temperature is high
R29 PFC RESET Warning
Rectifier module power on
R30 PLEASE WAIT Warning
Rectifier waits as adjusted startup delay
R31 RECTIFIER START Warning
Rectifier is in soft start stage
L01 TH1 TEMP HIGH Warning
TH1 temperature is high
L02 TH2 TEMP HIGH Warning
TH2 temperature is high
L03 TH1 TEMP LOW Warning
TH1 temperature is low
L04 TH2 TEMP LOW Warning
TH2 temperature is low
L05 FAN MAINT Warning
FAN maintenance time
L06 BATTERY MAINT Warning
Battery maintenance time
L07 OPT MAINTENANCE Warning
Optional maintenance time
L08 TH1 SENSOR FAIL Warning
TH1 temperature sensor failure
L09 TH2 SENSOR FAIL Warning
TH2 temperature sensor failure
L10 ENTER FAULT RESET Warning
UPS is waiting fault reset for startup
L11 BATT CB OPEN Warning
External interactive battery switch is off
L12 GENERAL MAINT Warning
General maintenance time
L13 PFC CAN COMM ERR Warning
PFC module CAN communication timeout
L14 INV CAN COMM ERR Warning
INV module CAN communication timeout
Inverter module alarm codes
INV CODE = 0XXX Current inverter modüle status code
A00 INV FAULT = XXXX Hata XXXX fault occured at the inverter module
CALL SERVICE !
A01 O/P OVERCURRENT Alarm IGBT saturation alarm on inverter module
A02 OVERTEMP SHUT Alarm Overtemperature at inverter power module
A03 BATT HIGH Alarm Inverter module measured battery voltage high
A04 OUTPUT V.LOW Alarm Inverter output voltage is low
A05 OUTPUT V.HIGH Alarm Inverter output voltage is high
A06 OVERLOAD SHUT Alarm Overload at UPS output
A07 SHORT CIRCUIT Alarm Short circuit at UPS output
A08 ON MAINTENANCE Alarm Maintenance by-pass switch on
A09 MANUAL BYPASS Alarm Load is transferred to by-pass from front panel
A10 BATTERY LOW SHUT Alarm Inverter measured battery voltage is low (shutdown level)
A11 REPO STOP Alarm External REPO input signal sensed
A12 DC BALANCE BAD Alarm Before inverter start fitler capacitors dont discharged
A13 PEAK CURRENT Alarm Very high current at the UPS output
A14 INV NOT START Alarm Inverter module start failed
A17 BYPASS FAILURE Warning
By-pass input voltage failure
A18 BYPASS VOLT Warning
By-pass input voltage out of tolerance
A19 BYP FREQ.TOLER Warning
By-pass input frequency out og tolerance
A20 OVERLOAD Warning
Currently the load exceeded 100% capacity
A21 OVERTEMP Warning
Currently inverter power modul heatsink temperature is high
A22 OUTPUT OFF Warning
There is no UPS output voltage
A23 ON BYPASS Warning
Load is on bypass
A24 REVERSE CURRENT Warning
Regenerative backfeed to UPS output
A25 INV RESET Warning
Inverter module power on
A26 BATTERY LOW Warning
Batteries are going to full discharge
A27 GENERATOR MODE Warning
Generator set is running
A28 O/P PHASE LOSS Warning
Anyone of the UPS output phases there is no voltage
A29 SYNCHRON BAD Warning
Inverter is not synchron to by-pass input
A30 SHORT CIRCUIT Warning
Short circuit occured at the UPS output currenty normal
A31 OUTPUT SWITCH Warning
Output switch of the UPS is off
