31
400 DC bus voltage high
401 Inverter controller board power supply 1 out of tolerant
402 Inverter controller board power supply 2 out of tolerant
404 Inverter stop because (+)DC bus voltage is low
405 Inverter stop because (-)DC bus voltage is low
406 Inverter within time window 4 times DC bus voltage is high
INV General status codes tablos
500 Inverter received remote power off signal from RS232
501 Inverter received remote power off signal from CAN interface
502 Inverter sensed IGBT fault alarm 4 times within time window (30 minutes)
503 Inverter sensed Overtemperature alarm 4 times within time window (30 minutes)
504 Inverter sensed 3 phase AC O/P voltage low alarm 4 times within time window (30 minutes)
505 Inverter sensed 3 phase AC O/P voltage high alarm 4 times within time window (30 minutes)
506 Inverter Timeout error during eprom read or write
507 Inverter Memory checksum error
508 Inverter 3 output phases overloaded output shutdown
509 Inverter maintenance by-pass switch closed
510 Inverter IGBT fault error
511 Inverter overtemperature shutdown
512 Inverter 3 phase AC output voltage low
513 Inverter 3 phase AC output voltage high
514 Inverter output CB energized but still it looks like not energized
515 Inverter output CB not energized but stil it looks like energized
516 Inverter fault occured for restart password required
517 Inverter output CB energized but at the UPS output there is no 3 phase AC voltage
518 Inverter By-pass voltage is OK but at the UPS output there is no 3 phase AC voltage
INV Control activity status codes
612 INV Over RS232 interface battery quantity updated
613 INV Over CAN1 interface battery quantity updated
614 INV Over RS232 interface by-pass and output frequency updated
615 INV Over CAN1 interface by-pass and output frequency updated
616 INV Over RS232 interface By-pass and output voltage updated
617 INV Over CAN1 interface By-pass and output voltage updated
618 INV Over RS232 interface factory options updated
619 INV Over CAN1 interface factory options updated
620 INV Over RS232 interface user options updated
621 INV Over CAN1 interface user options updated
622 INV Over RS232 interface general test command received
623 INV Over CAN1 interface general test command received
624 INV Over RS232 interface transfer load to by-pass command received
625 INV Over CAN1 interface transfer load to by-pass command received
626 INV Over RS232 interface transfer load to UPS command received
627 INV Over CAN1 interface transfer load to UPS command received
628 INV Over RS232 interface Copy operating RAM to Factory settings zone command received
629 INV Over CAN1 interface Copy operating RAM to Factory settings zone command received
630 INV Over RS232 interface Copy factory settings to operating RAM command received
631 INV Over CAN1 interface Copy factory settings to operating RAM command received
632 INV Over RS232 interface Copy operating RAM to User settings zone command received
633 INV Over CAN1 interface Copy operating RAM to User settings zone command received
634 INV Over RS232 interface regenerative back feed activated
635 INV Over CAN1 interface regenerative back feed activated
