6. Specifications
MODEL
3/1 10K(L)
3/1 15K(L)
3/1 20K(L)
CAPACITY*
10000 VA / 8000 W
15000 VA / 12000 W
20000 VA / 16000 W
INPUT
Voltage Range
Low Line Loss
110 VAC ± 3 % at 50% Load;
176 VAC ± 3 % at 100% Load
Low Line Comeback
Low Line Loss Voltage + 10V
High Line Loss
300 VAC ± 3 %
High Line Comeback
High Line Loss Voltage - 10V
Frequency Range
46Hz ~ 54 Hz @ 50Hz system
56Hz ~ 64 Hz @ 60Hz system
Phase
Three phase with ground
OUTPUT
Output voltage
208/220/230/240VAC
AC Voltage Regulation
± 1%
Frequency Range
(Synchronized Range)
46Hz ~ 54 Hz @ 50Hz system
56Hz ~ 64 Hz @ 60Hz system
Frequency Range (Batt. Mode)
50 Hz ± 0.1 Hz or 60Hz ± 0.1Hz
Overload
AC mode
100%~110%: 30min;
110%~130%: 5min;
>130% : 1sec
100%~110%: 15min;
110%~130%: 30sec;
>130% : 1sec
100%~110%: 5min;
110%~130%: 1sec;
>130% : Immediately
Battery mode
100%~110%: 3min;
110%~130%: 30sec;
>130% : 1sec
100%~110%: 1min;
110%~130%: 5sec;
>130% : Immediately
100%~110%: 1min;
110%~130%: 1sec;
>130% : Immediately
Current Crest Ratio
3:1 max
Harmonic Distortion
≦ 3 % THD (Linear Load)
≦ 5 % THD (Non-linear Load)
Transfer Time
Line Battery
0 ms
Inverter Bypass
0 ms
EFFICIENCY
AC mode
> 91%
Battery Mode
> 91%
BATTERY
Standard
Model
Battery Type
12 V / 9 Ah
Numbers
16 pcs
20 pcs
16 pcs
20 pcs
16 pcs x 2 strings
(expandable to 40 pcs)
Recharge Time
9 hours recover to 90% capacity
Charging Current
Default : 1 A ± 10%
Max.: 1A
Charging Voltage
218.4V ± 1%
273 V ± 1%
218.4V ± 1%
273 V ± 1%
218.4V ± 1%
273 V ± 1%
Long-run
Model
Type
12V,Battery capacity depending on applications
Numbers
16 pcs
20 pcs
16 pcs
20 pcs
16 pcs
20 pcs
Charging Current
Default: 4 A ± 10%
Max.: 1A, 2A, 4A(Adjustable)
Charging Voltage
218.4V ± 1%
273 V ± 1%
218.4V ± 1%
273 V ± 1%
218.4V ± 1%
273 V ± 1%
PHYSICAL
Standard
Model
Dimension,DXWXH(mm)
442 x 190 x 688
815 x 250 x 826
Net Weight (kgs)
66
76
67
78
125
Long-run
Model
Dimension, DXWXH(mm)
442 x 190 x 318
575 x 190 x 318
Net Weight (kgs)
15
16
18.95
ENVIRONMENT
Operation Temperature
0 ~ 50°C
(battery life cycle will be shorten when temperature is above 25°C)
Operation Humidity
<95 % and non-condensing
Operation Altitude**
<1000m
Acoustic Noise Level
Less than 60dB @ 1 Meter
MANAGEMENT
Smart RS-232 or USB
Supports Windows® 2000/2003/XP/Vista/2008/7/8, Linux and MAC
Optional SNMP
Power management from SNMP manager and web browser
* Derate capacity to 60% of capacity in CVCF mode and to 90% when the output voltage is adjusted to 208VAC.
**If the UPS is installed or used in a place where the altitude is above than 1000m, the output power must be derated one percent per 100m.
***Product specifications are subject to change without further notice.
