TestEquity F4T Addendum

Chapter 3 – Communications
Page 18 TestEquity F4T Controller
SCPI Programming Mode
SCPI commands are ASCII text strings with a wide array of defined SCPI commands, all of
which are not included in this implementation. The SCPI protocol is only available over Ethernet
port 5025. The only available SCPI commands for the F4T are shown below. This complete list
is only valid for Firmware Revision 04:05:0007, released May 23, 2019 and higher. Older
firmware versions do not include all these commands. This list only applies to the native F4T
Ethernet interface, NOT the external Serial Modbus-to-Ethernet Converter.
Description
SCPI Command
SCPI Values
R/W
Comments
Commands for Process Units
Query Comm. Temperature units
:UNIT:TEMPERATURE?
C|F
R
Ethernet units
Set Comm. Temperature units to F
:UNIT:TEMPERATURE F
W
Ethernet units to Fahrenheit
Set Comm. Temperature units to C
:UNIT:TEMPERATURE C
W
Ethernet units to Celsius
Query Display Temperature units
:UNIT:TEMPERATURE:DISPLAY?
C|F
R
Front panel display units
Set Display Temperature units to F
:UNIT:TEMPERATURE:DISPLAY F
W
Front panel display units to Fahrenheit
Set Display Temperature units to C
:UNIT:TEMPERATURE:DISPLAY C
W
Front panel display units to Celsius
This list is ONLY for versions WITH Cascade Control (Part Temperature Control). NOT for standard Temperature or Temperature/Humidity chambers.
Read Set Point (Cascade)
:SOURce:CAScade1:SPOint?
<floating point value>
R
User set point
Write Set Point (Cascade)
:SOURce:CAScade1:SPOint <value>
W
User set point
Read Outer Loop PV (Cascade)
:SOURce:CAScade1:OUTer:PVALue?
<floating point value>
R
Source Value A
Query Outer Loop Input Error (Cascade)
:SOURce:CAScade1:OUTer:ERRor?
ERROR|NONE
R
Input error status
Read Inner Loop PV (Cascade)
:SOURce:CAScade1:INNer:PVALue?
<floating point value>
R
Source Value B
Query Outer Loop Input Error (Cascade)
:SOURce:CAScade1:INNer:ERRor?
ERROR|NONE
R
Input error status
Read Outer Loop Set Point (Cascade)
:SOURce:CAScade1:OUTer:SPOint?
<floating point value>
R
Read Inner Loop Set Point (Cascade)
:SOURce:CAScade1:INNer:SPOint?
<floating point value>
R
Query cascade loop function
:SOURce:CAScade1:FUNCtion?
R
Set cascade loop function to PROCESS
:SOURce:CAScade1:FUNCtion PROCESS
W
Not recommended, do not enter this
Set cascade loop function to DEVIATION
:SOURce:CAScade1:FUNCtion DEVIATION
W
Query cascade range low
:SOURce:CAScade1:RANGe:LOW?
<floating point value>
R
Set cascade range low
:SOURce:CAScade1:RANGe:LOW <value>
<floating point value>
W
Query cascade range high
:SOURce:CAScade1:RANGe:HIGH?
<floating point value>
R
Set cascade range high
:SOURce:CAScade1:RANGe:HIGH <value>
<floating point value>
W
Query cascade simple set point control
:SOURce:CAScade1#:SSPoint:CONTrol?
R
Set cascade simple set point control OFF
:SOURce:CAScade1:SSPoint:CONTrol OFF
W
Turns OFF Cascade Control mode
Set cascade simple set point control ON
:SOURce:CAScade1:SSPoint:CONTrol ON
W
Turns ON Cascade Control mode
Commands for Manual Ramp Parameters (ramping without running a profile)
Set ramping off
:SOURce:CLOop#:RACTion OFF
W
controls instantly to set point
Set ramping on startup
:SOURce:CLOop#:RACTion STArtup
W
ramps to set point on controller power
on
Set ramping on set point change
:SOURce:CLOop#:RACTion SETPoint
W
ramps to set point on change of set
point
Set ramping on both events
:SOURce:CLOop#:RACTion BOTH
W
ramps to set point on controller power
on OR change of set point
Write ramp scale to minutes
:SOURce:CLOop#:RSCAle MINutes
W
ramp rate is per minute
Write ramp scale to hours
:SOURce:CLOop#:RSCAle HOURS
W
ramp rate is per hour
Read ramp rate
:SOURce:CLOop#:RRATe?
<floating point value>
R
rate that controller ramps to set point
Read ramp time
:SOURce:CLOop#:RTIMe?
<floating point value>
R
time that controller ramps to set point
Write ramp rate
:SOURce:CLOop#:RRATe <value>
W
rate that controller ramps to set point
Read ramp time
:SOURce:CLOop#:RTIMe <value>
W
rate that controller ramps to set point
Commands for Event Outputs
Query output name
:OUTPut#:NAME?
# = outputs 1-7
Set event output ON
:OUTPut#:STATe ON
W
# = outputs 1-7
Set event output OFF
:OUTPUT#:STATE OFF
W
# = outputs 1-7
Query event output state
:OUTPut#:STATe?
OFF|ON
R
# = outputs 1-7
Continued on next page…
