9 Technical data
20
9 Technical data
9.1. General technical data
Feature Values
Operating temperature -10 °C to +50 °C
Storage temperature -15 °C to +60°C
Humidity 0 to 80% RH
Operating altitude Up to 2000 m
Measurement category testo 760-1: CAT III / 600 V
testo 760-2: CAT IV/600 V
testo 760-3: CAT IV/600 V
Level of contamination 2
Protection class IP 64 only valid when using the silicone caps
Power supply 3 × 1.5V (AAA/IEC LR03)
Battery status display Batt. icon appears from <3.9 V
Display 3 3/4 digit, LC display
Display range testo 760-1: 4000 digits)
testo 760-2/-3: 6000 digits
Polarity indicator Automatic
Overload protection
(fuse)
testo 760-1:
- F 10 A/600 V, ceramic, 6.3×32 mm, min. cut-
off current 20 kA
testo 760-2:
- F 10 A/600 V, ceramic, 6.3×32 mm, min. cut-
off current 30 kA
- F 630 mA/600 V, ceramic, 6.3×32 mm, min.
cut-off current 30 kA
testo 760-3:
- F 10 A/1000 V, ceramic, 10×38 mm, min. cut-
off current 30 kA
- F 630 mA/1000 V, ceramic, 6.3×32 mm, min.
cut-off current 30 kA
Dimensions (H x W x
D)
167x 85 x 45 mm
Weight 340 g
Safety standards EMV 2014/30/EU, EN 61326-1, Low Voltage
Directive 2014/35/EU with the standard EN 61010-
2-033, and insulation complying with class II IEC
536/DIN EN 61140
Certifications TÜV, CSA, CE
Warranty Duration: 2 years
Terms: see website www.testo.com/warranty
