TESTO 760 - 5 Overview; Display and Control Elements

5 Overview
6
5 Overview
5.1. Display and control elements
1 Control keys
2 LC display
3 Grip area
4 On the rear: battery compartment and bracket for the probe tips
5 On the rear: stand
6 Input jack
• testo 760-1: voltage, resistance, continuity, diode, capacitance and
frequency measurements
• testo 760-2/-3: voltage, resistance, continuity, diode, capacitance,
frequency, duty cycle and temperature measurements
7 Ground/COM jack for all measurements
8 Input jack for AC and DC mA/µA current measurement (up to 600 mA)
(testo 760-2/-3 only)
9 Input jack for AC and DC current measurement up to 10 A
