5 Overview
7
5.2. LC display
1 Direct current/voltage
2 Alternating current/voltage
3 Diode test and diode continuity
4 Low-pass filter
5 AUTO mode is the default setting in all measuring modes
6 Dangerous voltage, AC ≥ 50 V, DC ≥ 120 V
7 Maximum, minimum, average measurement
8 Hold is activated, LC display holds the current reading
9 Battery capacity display
Display Feature
No Symbol Battery capacity 100 – 30%
Battery capacity 30 - 15%
Battery capacity 15 - 2%
flashes and
acoustic
signal emitted
Battery capacity 2 – 0%, instrument switches off
automatically
10 Automatic power-off function is activated
11 Measuring units
12 Analog display (testo 760-2/-3 only)
13 Indication of polarity in bar chart (testo 760-2/-3 only)
