6 Using the product
53
Task Actions/description
Activate
sequence
> .
- A white, flashing dot (top right of the display)
indicates standby status until the start of
recording. When the Countdown start criterion
is selected, the remaining time until the start is
also displayed.
- The recording proceeds from the start criterion
entered. A red, flashing dot (top right of the
display) indicates that the recording is ongoing.
The number of images recorded is displayed to
the left of it. The file name is displayed at the
top left of the display.
Show / hide
configuration
settings
Function is only available when a sequence is
activated.
>
(hide) or (show).
Deactivate
sequence /
end recording
Function is only available when a sequence is
activated or when a recording is ongoing.
> .
Pos: 76 /TD/Produk t verwenden/WBKs/ testo 885/885, 890: Assis tenten: Panorama-Bil d, Messorterkennung @ 9\ mod_1312228055416_79 .docx @ 87876 @ 53555555555555 5 @ 1
Image stitching
The image stitching wizard can be used to produce a large
panoramic image from up to 3x 3 single images. The wizard helps
when recording the single images and ensures that there is
sufficient overlap for stitching together to create a panoramic image
using the PC software.
Before calling up the function, please note:
When the function is called up, the scale is set to manual and the
temperature scope at this time is fixed. This temperature scope
may not be sufficient for the entire panoramic image.
Recommendation:
> Scan the entire object for the panoramic image to determine the
required temperature scope (minimum/maximum measurement
value). Set scale to manual and set scale limits, see Scale
manual, page 45.
