6 Using the product
108
Designation Explanation
Marker
Symbol for the measurement points.
Degree of
regression
Possible values "0" to "7". The "0" degree
represents a pure mean calculation, the
"1" degree of regression the linear trend,
a higher value helps in the event of
curves with several extreme values.
Pos: 136 /TD/Produ kt verwenden/testo Sa veris/05a-2 Kur veneigenschaften/02 Register Grenzwertanzeig e @ 0\mod_11889967052 65_79.docx @ 3656 @ 5 @ 1
Range limits tab
Designation Explanation
Display area limit Specification as to whether the limit
values should be shown in the diagram.
Add limit labels Specification as to whether the limit
values should be labelled (Upper/Lower
limit value: name of curve).
Area fill Specification as to whether the areas
outside of the limit values should be
marked by means of an area fill.
Selection list for
area fill
Selection of the fill.
