7 Maintaining the product
162
Pos: 186 /TD/Leis tungsbeschreibung/ Technische Daten/ testo Saveris/06 Etherne t-Fühler @ 1\mod_1197559 409437_79.doc x @ 6435 @ 25555555 @ 1
7.10.4. Saveris Ethernet probes
The technical data listed in the following table are valid for all
Saveris Ethernet probes. Special data for the individual probe types
can be found in the following sections.
Feature Values
Housing dimensions
(W x H x D)
85 x 100 x 38 mm
Power supply
6.3 V DC mains unit;
alternatively via 24 V AC/DC plug-
in/screw terminals, PoE
Buffer battery
5
Li-ion
Housing material Plastic
Protection class IP54
Measuring cycle 2 sec - 24 h
Operating
temperature
+5 ... +45 °C
Storage
temperature
- 25 ... +60 °C
Display (optional) 2-line LCD; 7 segments with symbols
Wall holder Included
Power consumption PoE class 0 (typically ≤ 3 W)
Warranty
2 years, for warranty conditions see web
page www.testo.com/warranty
5
Wearing part
