Battery Charge
After selecting this mode, you can charge batteries separately. For information about the setting
method and display mode, refer to Capacity Test. After you press ENTER, the tester charges the
selected battery. When the charge is completed, the whole process ends.
Battery Discharge
After selecting this mode, you can discharge batteries separately. For information about the setting
method and display mode, refer to Capacity Test. After you press ENTER, the tester discharges the
selected battery. When the discharge is completed, the whole process ends.
Program DC Power
Select this mode, and then press ENTER to DC power supply mode, as shown below.
Constant voltage mode The tester is On.
Setting voltage..... Output voltage
Setting current..... Output current
By default, the power supply is disabled. Press ENTER to enable the power output, or press enter
again to disable it.
1.
CV:
The
battery
is
working
in
constant-voltage
mode;
CC:
The
battery
is
working
in
constant-current mode.
2. ON: The tester is switched on; Off: The tester is switched off.
3. Vs=1.00V: The voltage is set to 1.00V.
4. Is=1.00A: The maximum output current is set to 1A.
5. Vo=1.00V: The current output voltage is 1.00V.
DC Power Supply
CV ON
->Vs= 1.00V Vo= 1.00V
Is= 1.00A Io= 0.090A
