VOL and IMP
After this function is selected, the tester actually acts as a voltage & resistance meter to
continuously display the following parameters of the tested battery.
Battery voltage
Battery impedance
Identification resistor R1
Identification resistor R2
Description of the displayed items:
1. The battery voltage is 5.74V.
2. The battery impedance is 672 mΩ.
3. The ID1 resistor is open-circuit.
4. The ID2 resistance is 8.4 KΩ.
If the voltage indication is “+/-“, it indicates that the battery is connected reversely.
If the indication of impedance or identification resistor is OVER, it indicates that the impedance or
resistance exceeds the measurement range or is open-circuit.
Press ESC to exit the current test.
VOLTAGE: 5.74 V
IMPEDANCE: 672mΩ
ID1(RES): OVER KΩ
ID2(RES): 8.4 KΩ
