7. PRE-USE PREPARATION
ATLAS X (MADE IN EUROPE)
7.3 UNPACKING THE COMPONENTS
• Carefully open the packaging.
• Check the shipment for completeness (refer to the shipping documents).
• Separate the packaging material and dispose of it in an environmentally
responsible way.
7.4 ASSEMBLING THE WIND TURBINE
Turbine Body:
• Take out the shaft and flanges out of the box.
• Double holes of the shaft will be down side, single hole upside.
• Use bottom and top flanges to be connected to the shaft.
• Flange screwing holes for the blades should be matched when you look at
them from the top.
• Connect flange-shaft parts to the body now and use screws for the bottom
hole to make it tight. Use white belts to merge the bottom and top wings.
