23
7. PRE
-USE PREPARATION
ATLAS X (MADE IN EUROPE)
7.5 ELECTRICAL CONNECTIONS
• Wind Turbine has 3 phase AC connection. These connections are to be con-
nected with TESUP Charge Controller.
• The output of the charge controller can be then connected in two ways:
• The Output of the charge controller can be connected to the battery.
• The Output of the charge controller can be connected to the power grid
using the inverter.
• The cables from charge controller to the battery or the power grid will be DC
connection.
• Cable Lengths and cross sections should be as follows:
WARNING: All work on electrical equipment must be carried out by a
qualified electrician with the power switched off!
NOTE: To ensue proper operation, you must use an original TESUP
charge controller.
Length <11 m <18 m <29 m <44 m <68 m <110 m
Cross-
section
2.5 sq.
mm
4 sq.
mm
6 sq.
mm
10 sq.
mm
16 sq.
mm
25 sq.
mm
CABLE DETAILS
