3.1 Mop Assembly
4. Assemble Product
Insert handle assembly into top of machine body from the direction as shown in
figure; snap positioning is set inside; assembling is successful when a “ka”
sound is heard.
To disassemble handle assembly, insert a hard <4.5 mm-diameter column (such
as screwdriver, iron wire or wooden strip) into the snap hole on machine body
until it reaches bottom, slowly pull out handle assembly.
4.1 Assemble Machine Body and Handle Assembly
Snap Hole
6
UV Disinfection Lamp
Floor Penetrating
Rear Wheel
Small Wheel
Roller Brush
Scraper
