Event-Trigger Submodule Registers
Table 4-24. Event-Trigger Prescale Register (ETPS) Field Descriptions (continued)
Bits Name Description
9-8 SOCAPRD ePWM ADC Start-of-Conversion A Event (EPWMxSOCA) Period Select
These bits determine how many selected ETSEL[SOCASEL] events need to occur before an
EPWMxSOCA pulse is generated. To be generated, the pulse must be enabled
(ETSEL[SOCAEN] = 1). The SOCA pulse will be generated even if the status flag is set from
a previous start of conversion (ETFLG[SOCA] = 1). Once the SOCA pulse is generated, the
ETPS[SOCACNT] bits will automatically be cleared.
00 Disable the SOCA event counter. No EPWMxSOCA pulse will be generated
01 Generate the EPWMxSOCA pulse on the first event: ETPS[SOCACNT] = 0,1
10 Generate the EPWMxSOCA pulse on the second event: ETPS[SOCACNT] = 1,0
11 Generate the EPWMxSOCA pulse on the third event: ETPS[SOCACNT] = 1,1
7-4 Reserved Reserved
3-2 INTCNT ePWM Interrupt Event (EPWMx_INT) Counter Register
These bits indicate how many selected ETSEL[INTSEL] events have occurred. These bits are
automatically cleared when an interrupt pulse is generated. If interrupts are disabled,
ETSEL[INT] = 0 or the interrupt flag is set, ETFLG[INT] = 1, the counter will stop counting
events when it reaches the period value ETPS[INTCNT] = ETPS[INTPRD].
00 No events have occurred.
01 1 event has occurred.
10 2 events have occurred.
11 3 events have occurred.
1-0 INTPRD ePWM Interrupt (EPWMx_INT) Period Select
These bits determine how many selected ETSEL[INTSEL] events need to occur before an
interrupt is generated. To be generated, the interrupt must be enabled (ETSEL[INT] = 1). If
the interrupt status flag is set from a previous interrupt (ETFLG[INT] = 1) then no interrupt will
be generated until the flag is cleared via the ETCLR[INT] bit. This allows for one interrupt to
be pending while another is still being serviced. Once the interrupt is generated, the
ETPS[INTCNT] bits will automatically be cleared.
Writing a INTPRD value that is the same as the current counter value will trigger an interrupt
if it is enabled and the status flag is clear.
Writing a INTPRD value that is less than the current counter value will result in an undefined
state.
If a counter event occurs at the same instant as a new zero or non-zero INTPRD value is
written, the counter is incremented.
00 Disable the interrupt event counter. No interrupt will be generated and ETFRC[INT] is
ignored.
01 Generate an interrupt on the first event INTCNT = 01 (first event)
10 Generate interrupt on ETPS[INTCNT] = 1,0 (second event)
11 Generate interrupt on ETPS[INTCNT] = 1,1 (third event)
Figure 4-25. Event-Trigger Flag Register (ETFLG)
15 8
Reserved
R-0
7 4 3 2 1 0
Reserved SOCB SOCA Reserved INT
R-0 R-0 R-0 R-0 R-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
SPRU791D – November 2004 – Revised October 2007 Registers 113
