6.3 Bill of Materials
This section shows the bill of materials separately for the SENS063 and SENS064
6.3.1 SENS063 (INA228EVM, INA237EVM, INA238EVM)
Table 6-1 through Table 6-4 provide the parts list for the EVM. Table 6-1 through Table 6-3 are variant specific, while Table 6-4 shows the parts common
to all SENS063 variants.
Table 6-1. INA228EVM Exclusive Bill of Materials
Designator QTY Value Description Package Reference Part Number Manufacturer
U1 1 85-V, High-Voltage, Zero-Drift, 20-Bit ADC, I2C, Bidirectional Shunt Current, Bus
Voltage, Power, Temperature, Energy and Charge Monitor, DGS0010A (VSSOP-10)
DGS0010A INA228AIDGSR Texas Instruments
Table 6-2. INA237EVM Exclusive Bill of Materials
Designator QTY Value Description Package Reference Part Number Manufacturer
U1 1 85-V, High-Voltage, Zero-Drift, 16-Bit ADC, I 2C, Bidirectional Shunt Current, Bus
Voltage, Power, and Temperature Monitor
DGS0010A INA237AIDGSR Texas Instruments
Table 6-3. INA238EVM Exclusive Bill of Materials
Designator QTY Value Description Package Reference Part Number Manufacturer
U1 1 85-V, High-Voltage, Zero-Drift, 16-Bit ADC, I 2C, Bidirectional Shunt Current, Bus
Voltage, Power, and Temperature Monitor
DGS0010A INA238AIDGSR Texas Instruments
Table 6-4. SENS063 Variants Bill of Materials
Designator QTY Value Description Package Reference Part Number Manufacturer
!PCB1 1 Printed Circuit Board SENS063 Any
C1 1 1uF CAP, CERM, 1 µF, 16 V,+/- 20%, X5R, 0402 0402 GRM155R61C105MA12D
MuRata
C2 1 0.1uF CAP, CERM, 0.1 uF, 50 V, +/- 20%, X7R, 0402 0402 GRM155R71H104ME14D MuRata
D1, D2 2 White LED, White, SMD 0805 VAOL-S8WR4 Visual Communications
Company, LLC
H1, H2, H3,
H4
4 Bumpon, Hemisphere, 0.25 X 0.075, Clear 75x250 mil SJ5382 3M
H5 1 Kitting Item: SCB Controller SENS077 Texas Instruments
H6 1 Kitting Item: 3025010-03; Cable, USB A MALE to Micro B MALE 3'; CDDS 6612041 6612041 Qualtek
J1 1 TERM BLK 6POS SIDE ENTRY 5MM PCBASSEMBLY NOTE: Trim leads per ZZ5 HDR6 691137710006 Wurth Electronics
J2 1 Receptacle, 2mm, 6x2, Gold, R/A, TH Receptacle, 2mm, 6x2, R/A,
TH
NPPN062FJFN-RC Sullins Connector Solutions
J3 1 'Connector Header Through Hole, Right Angle 12 position 0.079" (2.00mm) HDR12 NRPN062PARN-RC Sullins Connector Solutions
LBL1 1 Thermal Transfer Printable Labels, 0.650" W x 0.200" H - 10,000 per roll PCB Label 0.650 x 0.200 inch THT-14-423-10 Brady
R2, R3 2 0 RES, 0, 5%, 0.125 W, 0603 0603 MCT06030Z0000ZP500 Vishay/Beyschlag
R4, R7 2 10k RES, 10 k, 5%, 0.063 W, AEC-Q200 Grade 0, 0402 0402 CRCW040210K0JNED Vishay-Dale
R5, R6, R8 3 4.7k RES, 4.7 k, 5%, 0.063 W, AEC-Q200 Grade 0, 0402 0402 CRCW04024K70JNED Vishay-Dale
SW0, SW1 2 Slide Switch SP4T Surface Mount, Right Angle SMT_SW_11MM3_4MM1 CUS-14TB Nidec Copal Electronics
Schematics, PCB Layout, and Bill of Materials www.ti.com
28 INA228, INA229, INA237, INA238, and INA239 EVM User’s Guide SBOU241C – APRIL 2020 – REVISED JULY 2021
