Table 6-4. SENS063 Variants Bill of Materials (continued)
Designator QTY Value Description Package Reference Part Number Manufacturer
TP1, TP2,
TP3, TP4,
TP5, TP6,
TP7, TP8,
TP9, TP10,
TP11, TP12
12 Test Point, Miniature, SMT Testpoint_Keystone_Miniatur
e
5015 Keystone
C3 0 0.1uF CAP, CERM, 0.1 uF, 100 V, +/- 10%, X7S, AEC-Q200 Grade 1, 0603 0603 CGA3E3X7S2A104K080AB TDK
FID1, FID2,
FID3
0 Fiducial mark. There is nothing to buy or mount. N/A N/A N/A
R1 0 10 mOhms ±0.5% 2W Chip Resistor 2512 (6432 Metric) Automotive AEC-Q200,
Current Sense, Moisture Resistant Metal Film
2512 PCS2512DR0100ET Ohmite
6.3.2 SENS064 (INA229EVM, INA239EVM)
Table 6-5 through Table 6-7 provide the parts list for the EVM. Table 6-5 and Table 6-6 are variant specific, while Table 6-7 shows the parts common to all
SENS064 variants.
Table 6-5. INA229EVM Exclusive Bill of Materials
Designator QTY Value Description Package Reference Part Number Manufacturer
U1 1 85-V, High-Voltage, Zero-Drift, 20-Bit ADC, SPI, Bidirectional Shunt Current, Bus
Voltage, Power, and Temperature, Energy and Charge Monitor, DGS0010A (VSSOP-10)
DGS0010A INA229AIDGSR Texas Instruments
Table 6-6. INA239EVM Exclusive Bill of Materials
Designator QTY Value Description Package Reference Part Number Manufacturer
U1 1 85-V, High-Voltage, Zero-Drift, 16-Bit ADC, SPI, Bidirectional Shunt Current, Bus
Voltage, Power, and Temperature Monitor
DGS0010A INA239AIDGSR Texas Instruments
Table 6-7. SENS046 Variants Bill of Materials
Designator QTY Value Description Package Reference Part Number Manufacturer
!PCB1 1 Printed Circuit Board SENS064 Any
C1 1 1uF CAP, CERM, 1 µF, 16 V,+/- 20%, X5R, 0402 0402 GRM155R61C105MA12D MuRata
C2 1 0.1uF CAP, CERM, 0.1 uF, 50 V, +/- 20%, X7R, 0402 0402 GRM155R71H104ME14D MuRata
D1, D2 2 White LED, White, SMD 0805 VAOL-S8WR4 Visual Communications
Company, LLC
H1, H2, H3,
H4
4 Bumpon, Hemisphere, 0.25 X 0.075, Clear 75x250 mil SJ5382 3M
H5 1 Kitting Item: SCB Controller SENS077 Texas Instruments
H6 1 Kitting Item: 3025010-03; Cable, USB A MALE to Micro B MALE 3'; CDDS 6612041 6612041 Qualtek
J1 1 TERM BLK 6POS SIDE ENTRY 5MM PCBASSEMBLY NOTE: Trim leads per ZZ5 HDR6 691137710006 Wurth Electronics
J2 1 Receptacle, 2mm, 6x2, Gold, R/A, TH Receptacle, 2mm, 6x2, R/A,
TH
NPPN062FJFN-RC Sullins Connector Solutions
J3 1 Connector Header Through Hole, Right Angle 12 position 0.079" (2.00mm) HDR12 NRPN062PARN-RC Sullins Connector Solutions
LBL1 1 Thermal Transfer Printable Labels, 0.650" W x 0.200" H - 10,000 per roll PCB Label 0.650 x 0.200
inch
THT-14-423-10 Brady
