Table 6-7. SENS046 Variants Bill of Materials (continued)
Designator QTY Value Description Package Reference Part Number Manufacturer
R2, R3, R7,
R8, R9, R10
6 0 RES, 0, 5%, 0.125 W, 0603 0603 MCT06030Z0000ZP500 Vishay/Beyschlag
R4, R5 2 10k RES, 10 k, 5%, 0.063 W, AEC-Q200 Grade 0, 0402 0402 CRCW040210K0JNED Vishay-Dale
R6 1 4.7k RES, 4.7 k, 5%, 0.063 W, AEC-Q200 Grade 0, 0402 0402 CRCW04024K70JNED Vishay-Dale
SW1 1 Slide Switch SP4T Surface Mount, Right Angle SMT_SW_11MM3_4MM1 CUS-14TB Nidec Copal Electronics
TP1, TP2,
TP3, TP4,
TP5, TP6,
TP7, TP8,
TP9, TP10,
TP11, TP12
12 Test Point, Miniature, SMT Testpoint_Keystone_Miniatur
e
5015 Keystone
C3 0 0.1uF CAP, CERM, 0.1 uF, 100 V, +/- 10%, X7S, AEC-Q200 Grade 1, 0603 0603 CGA3E3X7S2A104K080AB TDK
FID1, FID2,
FID3
0 Fiducial mark. There is nothing to buy or mount. N/A N/A N/A
R1 0 10 mOhms ±0.5% 2W Chip Resistor 2512 (6432 Metric) Automotive AEC-Q200, Current
Sense, Moisture Resistant Metal Film
2512 PCS2512DR0100ET Ohmite
