6 Bill of Materials
TPS7H5001-SP Bill of Materials lists the EVM bill of materials (BOM).
Table 6-1. TPS7H5001-SP Bill of Materials
Designator Quantity Value Description Package Reference Part Number Manufacturer
!PCB1 1 Printed Circuit Board NA Any
C1 1 150µF Molded Tantalum Polymer Capacitor 20V
2917 (7343 Metric) 50mOhm @ 100kHz
2917 T521D157M020ATE050 Kemet
C2, C3 2 10uF CAP, CERM, 10 uF, 50 V, ±10%, X5R, 1206 1206 GRM31CR61H106KA12L MuRata
C4 1 0.1uF CAP, CERM, 0.1 uF, 50 V, ±5%, X7R, 1206 1206 12065C104JAT2A AVX
C5, C6, C7, C8, C17 5 20pF CAP, CERM, 20 pF, 100 V, ±5%, C0G/NP0, 0805 0805 08051A200JAT2A AVX
C9, C20, C23, C27, C35 5 0.1uF CAP, CERM, 0.1 uF, 25 V, ±10%, X7R, 0805 0805 C0805C104K3RACTU Kemet
C10 1 500pF CAP, CERM, 500 pF, 50 V,±2%, C0G/NP0, 0805 0805 08055A501GAT2A AVX
C15 1 0.47uF CAP, CERM, 0.47 uF, 50 V, ±10%, X7R, AEC-Q200
Grade 1, 0805
0805 GCM21BR71H474KA55L MuRata
C16 1 0.01uF CAP, CERM, 0.01 uF, 50 V, ±5%, X7R, 0805 0805 08055C103JAT2A AVX
C18 1 1uF CAP, CERM, 1 uF, 50 V, ±10%, X7R, 0805 0805 08055C105KAT2A AVX
C21, C24, C28, C36 4 1uF CAP, CERM, 1 uF, 50 V, ±10%, X7R, 0805 0805 885012207103 Wurth Elektronik
C22, C25, C29, C37 4 1000pF CAP, CERM, 1000 pF, 50 V, ±10%, X7R, 0805 0805 C0805C102K5RACTU Kemet
C30 1 100uF CAP, Tantalum Polymer, 100 µF, 35 V,±20%, 0.1
ohm, 7.3x6.1mm SMD
7.3x6.1mm TCN4107M035R0100 AVX
C31 1 47uF CAP, TA, 47 uF, 10 V, ±10%, 0.5 ohm, SMD 3528-21 TPSB476K010R0500 AVX
H1, H2, H3, H4 4 Machine Screw, Round, #4-40 x 1/4, Nylon, Philips
panhead
Screw NY PMS 440 0025 PH B&F Fastener Supply
H5, H6, H7, H8 4 Standoff, Hex, 0.5"L #4-40 Nylon Standoff 1902C Keystone
J1, J2, J3, J4 4 Compact Probe Tip Circuit Board Test Points, TH, 25
per
TH Scope Probe 131-5031-00 Tektronix
J5 1 Header, 100mil, 2x1, Tin, TH Header, 2 PIN, 100mil,
Tin
PEC02SAAN Sullins Connector
Solutions
J6 1 Header, 100mil, 3x1, Tin, TH Header, 3 PIN, 100mil,
Tin
PEC03SAAN Sullins Connector
Solutions
J11 1 Terminal Block, 5.08 mm, 2x1, Brass, TH 2x1 5.08 mm Terminal
Block
ED120/2DS On-Shore Technology
LBL1 1 Thermal Transfer Printable Labels, 0.650" W x
0.200" H - 10,000 per roll
PCB Label 0.650 x
0.200 inch
THT-14-423-10 Brady
Schematics www.ti.com
12 TPS7H5001-SP Evaluation Module SLVUBZ8 – JULY 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated
