Texas Instruments TPS7H5001-SP User Manual

Table 6-1. TPS7H5001-SP Bill of Materials (continued)
Designator Quantity Value Description Package Reference Part Number Manufacturer
R1, R2, R3, R12, R13, R17,
R18, R20, R32, R38, R42, R43,
R44, R48, R49, R53, R54, R55,
R59, R60, R61, R62, R63, R66,
R67, R68, R69, R70, R71, R74,
R75, R76, R77, R78, R79, R80,
R81, R82, R83, R84, R85, R87,
R88, R89, R90, R91, R92, R93,
R98, R99, R102, R103, R109,
R111
54 0 RES, 0, 5%, 0.125 W, 0603 0603 MCT06030Z0000ZP500 Vishay/Beyschlag
R4, R101 2 0 RES, 0, 5%, 1 W, AEC-Q200 Grade 0, 2512 2512 CRCW25120000Z0EG Vishay-Dale
R9, R10 2 10.0k RES, 10.0 k, 1%, 0.125 W, AEC-Q200 Grade 0,
0805
0805 CRCW080510K0FKEA Vishay-Dale
R14 1 1.00k RES, 1.00 k, 0.1%, 0.125 W, 0805 0805 RG2012P-102-B-T5 Susumu Co Ltd
R15 1 20.0k RES, 20.0 k, 0.1%, 0.125 W, 0805 0805 RG2012P-203-B-T5 Susumu Co Ltd
R24, R26 2 10.0 RES, 10.0, 0.1%, 0.1 W, 0805 0805 CRT0805-BY-10R0ELF Bourns
R25 1 3.90k RES, 3.90 k, 0.5%, 0.1 W, 0805 0805 RR1220P-392-D Susumu Co Ltd
R27 1 5.90k RES, 5.90 k, 1%, 0.125 W, AEC-Q200 Grade 0,
0805
0805 CRCW08055K90FKEA Vishay-Dale
R29, R30, R39 3 49.9k RES, 49.9 k, 0.1%, 0.125 W, 0805 0805 RG2012P-4992-B-T5 Susumu Co Ltd
R31 1 135k RES, 135 k, 0.1%, 0.125 W, 0805 0805 RT0805BRD07135KL Yageo America
R33 1 191k RES, 191 k, 1%, 0.125 W, AEC-Q200 Grade 0, 0805 0805 CRCW0805191KFKEA Vishay-Dale
R35 1 1.00Meg RES, 1.00 M, 0.5%, 0.1 W, 0805 0805 RR1220P-105-D Susumu Co Ltd
R36 1 1.0k RES, 1.0 k, 5%, 0.125 W, AEC-Q200 Grade 0, 0805 0805 CRCW08051K00JNEA Vishay-Dale
R40 1 30.0k RES, 30.0 k, 0.5%, 0.1 W, 0805 0805 RR1220P-303-D Susumu Co Ltd
R41 1 4.70k RES, 4.70 k, 1%, 0.5 W, AEC-Q200 Grade 0, 0805 0805 ERJ-P06F4701V Panasonic
R45, R46, R47, R86, R94, R95,
R96, R104, R105, R106, R118
11 0 RES, 0, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603 RMCF0603ZT0R00 Stackpole Electronics
Inc
R100 1 10 RES, 10, 5%, 35 W, DDPAK DDPAK TDH35P10R0JE Ohmite
TP1, TP9, TP17, TP18, TP19 5 Test Point, Multipurpose, Purple, TH Purple Multipurpose
Testpoint
5129 Keystone
TP2, TP8, TP16 3 Test Point, Multipurpose, Grey, TH Grey Multipurpose
Testpoint
5128 Keystone
TP3 1 Test Point, Multipurpose, Brown, TH Brown Multipurpose
Testpoint
5125 Keystone
TP4, TP5 2 Test Point, Multipurpose, White, TH White Multipurpose
Testpoint
5012 Keystone
TP7 1 Test Point, Multipurpose, Red, TH Red Multipurpose
Testpoint
5010 Keystone
www.ti.com Schematics
SLVUBZ8 – JULY 2021
Submit Document Feedback
TPS7H5001-SP Evaluation Module 13
Copyright © 2021 Texas Instruments Incorporated
