Table 6-1. TPS7H5001-SP Bill of Materials (continued)
Designator Quantity Value Description Package Reference Part Number Manufacturer
TP10 1 Test Point, Multipurpose, Blue, TH Blue Multipurpose
Testpoint
5127 Keystone
TP11, TP20, TP21, TP22,
TP23, TP24, TP25, TP26,
TP27
9 Test Point, Multipurpose, Orange, TH Orange Multipurpose
Testpoint
5013 Keystone
TP13, TP14 2 Test Point, Miniature, SMT Test Point, Miniature,
SMT
5019 Keystone
TP28, TP29, TP30, TP31 4 Test Point, Miniature, Black, TH Black Miniature
Testpoint
5001 Keystone
U1 1 Radiation-Hardness-Assured Si and GaN Dual
Output Controller
CFP22 TPS7H5001HKY-EM Texas Instruments
U2, U3 2 Single 2-Input Positive-AND Gate, DCK0005A,
LARGE T&R
DCK0005A SN74AHCT1G08DCKR Texas Instruments
U4 1 800mA Low-Dropout Linear Regulator, 4-pin
SOT-223
DCY0004A TLV1117-50DCY Texas Instruments
U5, U6 2 250 MHz, Rail-to-Rail I/O, CMOS Single Operational
Amplifier, 2.5 to 5.5 V, -40 to 125 degC, 5-pin SOT23
(DBV5), Green (RoHS & no Sb/Br)
DBV0005A OPA354AIDBVR Texas Instruments
C11 0 1000pF CAP, CERM, 1000 pF, 50 V, ±10%, C0G/NP0, 0805 0805 08055A102KAT2A AVX
C12 0 0.01uF CAP, CERM, 0.01 uF, 50 V, ±20%, X7R, 0805 0805 C0805C103M5RACTU Kemet
C13 0 0.47uF CAP, CERM, 0.47 uF, 50 V, ±10%, X7R, AEC-Q200
Grade 1, 0805
0805 GCM21BR71H474KA55L MuRata
C14 0 1uF CAP, CERM, 1 µF, 50 V,±5%, X7R, AEC-Q200
Grade 1, 1210
1210 C1210C105J5RACTU Kemet
C19, C32, C33, C38, C39 0 0.1uF CAP, CERM, 0.1 uF, 25 V, ±10%, X7R, 0805 0805 C0805C104K3RACTU Kemet
C26, C34 0 0.1uF CAP, CERM, 0.1 uF, 25 V, ±10%, X7R, 0603 0603 C0603X104K3RACTU Kemet
FID1, FID2, FID3 0 Fiducial mark. There is nothing to buy or mount. N/A N/A N/A
J7, J8, J9, J10 0 Header Mate, 2.54mm, 21x2 Pads to Mate with Mill-
Max_820-22-042-30-00
1101
820-22-042-30-001101_MA
TE
Mill-Max
R5, R6, R7, R8 0 1.00Meg RES, 1.00 M, 0.5%, 0.1 W, 0805 0805 RR1220P-105-D Susumu Co Ltd
R11, R16, R19, R22, R28, R34,
R37, R50, R51, R52, R56,
R57, R58, R64, R65, R72,
R73, R108, R110, R112, R113,
R114, R115, R116, R117
0 0 RES, 0, 5%, 0.125 W, 0603 0603 MCT06030Z0000ZP500 Vishay/Beyschlag
R21 0 10.0k RES, 10.0 k, 1%, 0.2 W, 0805 0805 MCU08050C1002FP500 Vishay/Beyschlag
R23, R97, R107 0 0 RES, 0, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 0603 RMCF0603ZT0R00 Stackpole Electronics
Inc
