8 INS154-4
Failure to observe the following precautions regarding the battery could lead to the
danger of heating, ignition or explosion:
• Do not throw into a fire
• Do not heat
• Do not over-charge
• Do not reverse charge
• Do not short-circuit
• Do not disassemble
• Replace only with the same or
equivalent type
Always observe local regulations when disposing of a battery.
Plastic bags can suffocate - always dispose of packaging carefully.
4. Technical Specification
Environmental
Volume
Azura 360, Tempest:
109dB Peak at 1m (A Weighting, 90°)
Odyssey 1E, 2E, 3E & 4E:
109dB Peak at 1m (A Weighting, 90°)
Odyssey 1, 2, 3 & 4:
115dB Peak at 1m (A Weighting, 90°)
Cut-Off Time:
≤15 minutes
Waterproof Coating: Conformal
Operating Temperature:
-25°C (-13°F) to +55°C (+131°F)
Storage Temperature:
-25°C (-13°F) to +60°C (+140°F)
EMC Environment: Residential / Commercial /
Light Industrial / Industrial
Electrical
Supply Voltage: 12VDC (nominal)
Current Drain (typical at 12VDC)
Quiescent: 15mA
Strobe: 110mA
Sounder
Azura 360, Tempest: 300mA
Odyssey 1E, 2E, 3E & 4E: 300mA
Odyssey 1, 2, 3 & 4: 425mA
Standby Battery
Type: NiMh Stack
Voltage: 7.2VDC (nominal)
Capacity: 320mAh
Flash Tube: 1Ws
Flash Rate: 1Hz (typical)*
†
Discharge Time (≤
≤≤
≤60VDC): ≤180 seconds
Comfort LEDs
Brightness: 100mcd (typical)
Flash Rate (tamper secure): 1Hz alternating (typical)
* The flash rate will reduce to 0.125Hz after flashing for one hour (1 flash every 8
seconds). This is a software feature to reduce power consumption and cannot be
disabled.
† The flash rate may reduce to 0.5Hz for supply voltages less than 12V
DC.
